scintillator crystal

CaF2 scintillator crystal

Product ID：scintillator crystal
QQ：17656473
Phone: 13816704237
Tel: 021-61531868
Email: sales@pjtelect.com
Time: 2019-12-25 12:17
FEEDBACK

Calcium Fluoride crystal shows good optical and thermo-mechanical properties, can be used for optical windows, lenses, prisms within a wide range from 130nm to 9μm. It has optical properties of isotropy, low absorption and low refractive index, which made CaF2 gain the unique advantages in the application of high power lasers.

Available material: Max. Diameter: 370mm

Property of CaF2:

Transmission Range	130 nm to 10 μm
Transmittance	>94% at 193 nm to 7.8 μm
Refractive Index	1.39908 at 5 μm
Reflection Loss	5.4% at 5 μm (both surfaces)
Absorption Coefficient	0.03 cm-1 at 2.6 μm to 2.9 μm
dn/dT	-10.6 x 10-6 /℃
Density	3.18 g/cm3
Melting Point	1360℃
